Tube Sheet Specification

  • Grade
  • 2062
  • Feature
  • Key Features of Tube Sheets Precision Drilling and Layout: Holes are machined with tight tolerances (e.g., mm) in triangular (maximum density) or square (easier cleaning) patterns. Ligaments: The vital metal space remaining between adjacent drilled holes, designed to maintain structural integrity. Tube Joints: Methods used to secure tubes include expansion, rolling, welding, or a combination for a leak-tight seal. Grooves: Machined, circumferential grooves inside the hole to enhance the mechanical locking of the tube. Cladding/Overlay: Application of a corrosion-resistant alloy (e.g., Inconel, stainless steel) bonded to a base metal to withstand harsh chemical environments. Gasket Surface/Sealing Face: A specialized, flat surface machined to ensure a tight, leak-proof seal between the shell and tube sides
  • Working Presssure
  • 150
  • Material
  • Mild Steel
  • Fittings
  • Flanges
  • Purity
  • 100%
  • Features
  • High Quality
  • Pressure Ratings
  • 150
  • Material Grade
  • 2062
  • Dimension (L*W*H)
  • 25 Millimeter (mm)
  • Application
  • Key Applications of Tube Sheets: Shell-and-Tube Heat Exchangers: The primary application is holding hundreds of tubes in place, ensuring efficient heat transfer while separating shell-side and tube-side fluids. Boilers & Steam Generators: They support fire tubes or water tubes, acting as a pressure-resistant boundary in steam generation. Condensers: Used in power plants to support tubes where steam is converted back into water. Process Equipment: Applied in petrochemical, fertilizer, and pharmaceutical industries for reactors and evaporators. HVAC & Refrigeration: Used in chiller and cooling systems. Schilthorn Precision Schilthorn Precision +8 Key Functions and Features: Sealing and Separation: Prevents cross-contamination between fluids. Structural Support: Prevents vibration and maintains tube alignment. Materials: Engineered for high pressure and temperature; often use cladding (e.g., stainless steel over carbon steel) for corrosion resistance. Types: Include standard, floating, and double-tube sheets for high-purity, critical, or leak-sensitive applications
  • Capacity
  • 1000 Ton
  • Diameter
  • 25 Millimeter (mm)
  • Product Type
  • Pipe Flanges
  • Standard
  • ANSI
  • Shape
  • Round
  • Surface
  • Painted, Galvanized, Black
  • Connection
  • Male
  • Technics
  • ERW
  • Pressure
  • Various PSI
  • Size
  • Various
  • Color
  • Black


Tube Sheet Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Delivery Time
  • 1 Hours


About Tube Sheet

Their primary function is to support and isolate the tubing. Since tube sheets are in contact with both fluids on the shell side and the tube side, they must have corrosion resistance and be sealed tightly to prevent fluids from gaining contact.
