Puddle Flange

Puddle Flange Specification

Connection Type
Joint

Material Grade
As Per BS Table 10

Port Size
25

Pressure Ratings
Various Ratings

Purity
100%

Pipe Type
ROUND

End Type
Flanges

Corrosion Resistant
100

Thread Type
As per Require

Fittings
Flanges

Features
High Quality

Dimension (L*W*H)
25 Meter (m)

Shape
Round

Usage
Water Tank /Wall

Material
Mild Steel/Stainless Steel

Application
Industrial

Feature
Puddle flanges are specialized, circular plates welded onto pipes to create a robust, watertight, and pressure-resistant seal when embedded in concrete walls or floors. Key features include high corrosion resistance (using SS or galvanized steel), secure, permanent sealing against seepage, and easy installation, typically in subterranean or hydraulic applications. Key Features of Puddle Flanges Watertight Sealing: Designed to create a superior seal for pipe penetrations through concrete, ensuring no leakage or seepage occurs, crucial for basements, tanks, and submerged, or underground pipelines. Durable & Corrosion Resistant: Constructed from robust materials like Stainless Steel (304/316), Mild Steel (with coatings), or High-Density Polypropylene (PP), ensuring long-term performance in wet environments. Structure Integration: The wide rim is designed to be cast directly into concrete, acting as an anchor that prevents the pipe from moving and prevents water from traveling along the pipe's outer surface. Versatile Application: Suitable for a wide range of uses, including swimming pools, water tanks, sewage treatment plants, lift pits, and high-rise building plumbing. Various Material & Size Options: Available in various sizes (e.g., 2 1/2" to 12" for PP, up to NPS 24" for steel) and materials, including specialized options like HDPE for environmental, and chemical resistance. Standard Compliance: Often manufactured to meet industry standards such as BS 4504, DIN 1988, or ASTM A182 to guarantee reliability. Installation Friendly: Designed for straightforward welding to pipes or, in the case of plastic,, secure joining, reducing installation time.

Working Presssure
Various

Surface Finish
Finish

Diameter
25 Meter (m)

Capacity
25 Pcs/hr

Grade
As Per BS 10 Table E

Product Type
Pipe Flanges

Standard
DIN

Surface
Shotblasted, Painted, Galvanized, Black

Connection
Male

Technics
ERW

Pressure
As per Requirements PSI

Size
Various Sizes

Color
black

Puddle Flange Trade Information

Minimum Order Quantity
10 Pieces

FOB Port
as per discuss

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Days after Acceptance (DA), Delivery Point (DP), Telegraphic Transfer (T/T), Letter of Credit (L/C), Cash Against Delivery (CAD)

Supply Ability
10000 Pieces Per Week

Delivery Time
1 Hours

Sample Available
No

Sample Policy
Within a certain price range free samples are available

Packaging Details
1. Packing and Material Details (Packaging) Protection: To prevent damage to the surface (especially for galvanized coatings), puddle flanges are typically packed in wooden crates or, for smaller items, in corrugated boxes filled with protective material. Packaging Type: Industrial-grade items areoften found in HDPE bags or wooden crates. Components Included: Often come with stainless steel (SS) tension bands for securing to the pipe. Marking: Packed items are marked with essential information including the manufacturer's brand, grade of material, lot number, size, and type. Tradeindia Tradeindia +4 2. Product Specifications (Material & Design) Materials: Common materials include Mild Steel (MS) with hot-dip galvanization, Stainless Steel (SS304/SS316), PVC, and Rubber/EPDM. Dimensions: Available in sizes ranging from 25 mm to over 1200 mm (1 inch to 48+ inches). Thickness: The flange plate is typically 6 mm thick or greater. Design: Features a central opening for the pipe and a wide collar to act as a barrier. The surface is often grooved or ribbed to provide better anchoring in concrete. Pressure Rating: Typically designed to withstand pressures of PN6, PN10, or PN16. Rajtilak Metal Rajtilak Metal +6 3. Installation and Sealing Method Placement: Installed during the construction phase, prior to pouring concrete. Securing: The flange is placed over the pipe and secured with bands or welded to ensure it does not move during concrete pouring. Sealing: To ensure a watertight seal, the flange is often embedded in the middle of the wall, providing at least 50mm of concrete coverage on all sides. Flexible Options: Rubber or NBR material options are used for superior sealing in high-pressure or chemically sensitive environments. VIPseal VIPseal +4 4. Key Applications Water Tanks: Essential for inlet/outlet pipes to prevent leakage. Basements & Foundations: Prevents groundwater seepage. Sewage/Drainage: Stops leakage in manholes and wastewater structures. Udhhyog Udhhyog +1 5. Standards and Pricing Standards: Commonly designed to meet ASME B16.5, ASTM A105, or ASTM A182 standards. Price Range: GI Puddle Flange (~INR 500 1200), SS Puddle Flange (~INR 900 2500), PVC Puddle Flange (~INR 300 800).

Main Export Market(s)
Asia, Western Europe, Middle East, Africa, Australia, Central America, North America, South America, Eastern Europe

Main Domestic Market
Karnataka, Lakshadweep, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, All India, South India, Central India, West India, North India, East India, Kerala, Mizoram, Meghalaya, Tamil Nadu, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report as per client specification.

About Puddle Flange

What Is The Purpose Of Puddle Flange?

Using a ASME B16.5 Puddle Flange ensures a watertight seal where pipes are able to pass through the walls of any structure underneath groundwater level. The stainless steel puddle flange And di puddle flange is typically used to seal around the outside of a pipe, in this case since the flange is required to pass through concrete structures. Since the 50mm puddle flange is to be installed during construction of the structure, they have to have a sturdy construction, longer service life and they have to deliver a good performance as well.

Puddle Flange Installation In Water Tank?

ASME B16.5 Puddle Flange are installed during the process of construction and they are a very effective way of sealing the area around the outside of the pipes that pass through different kinds of structures made from concrete. There are a number of benefits to using Carbon Steel Puddle Flange and some of these are: 1) Ease of installation. 2) Excellent strength. 3) Cost effective. 4) Can withstand heavy loads. 5) Can be installed in ceilings, walls and floors.
